Magnus MX21i TR LED Trinocular Microscope

Send Inquiry

Request To Call Back

Magnus MX21i TR LED Trinocular Microscope

Name: Magnus MX21i TR LED Trinocular Microscope
Brand: M/S Uvsar India
Price: 82185.0 INR
Availability: InStock

Price 82185.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Magnus MX21i TR LED Trinocular Microscope Specification

Spare Parts
Dust cover, immersion oil, fuse, lens cleaning paper, power cord.

Focus System
Coaxial coarse and fine focusing adjustment; precise and ergonomic.

Features
LED illumination, anti-fungal optics, ergonomic design, robust build, easy digital imaging adaptability.

View Head
Trinocular, 360 rotatable, 30 inclined.

Theory
Trinocular Microscope with advanced optical features for routine and research applications.

Drawtube
Trinocular (Seidentopf) head, 30 inclined, 360 rotatable.

Sensor
CMOS (when camera is attached, camera not included as standard).

Resolution
Varies with camera attachment; up to 1920 x 1080 pixels with compatible digital camera.

Interface
USB 2.0 (for camera, optional accessory).

Frame Rate
Up to 30fps with compatible camera.

Focal Distance
Standard dovetail; coarse and fine focusing mechanism, typically 37.7mm parfocal distance.

Magnification
40X to 1000X (Standard configuration: 4X, 10X, 40X, 100X oil).

Dimensions
Approx. 380mm (H) x 220mm (W) x 190mm (D).

Focus Range
Coarse: 25mm, Fine: 0.002mm per division.

Eyepieces
Wide field 10X/20mm, focusable, anti-fungal.

Eyepiece Tube
Trinocular, suitable for digital imaging and observation.

Illumination
LED illumination with variable intensity; life: up to 35,000 hours.

Coarse Adjustment Range
25mm total travel.

Fine Adjustment Range
0.002mm per graduation.

Working Stage
Double layer mechanical stage, 145mm x 140mm with 75mm x 55mm travel.

Still Image Capture Resolution
Up to 5MP with digital camera (not included).

Video Capture Resolution
1080p Full HD (with optional camera).

Image Format
JPEG, BMP, AVI (optional digital camera required).

Interpupillary Distance
48mm - 75mm adjustable.

Objective Achromatic
Infinity corrected achromatic objectives: 4X, 10X, 40X (spring), 100X oil (spring).

Condenser
Abbe condenser, N.A. 1.25 with iris diaphragm and filter holder.

Light Source
Built-in LED (3W), low heat and long life.

Stage Travel Range
75mm (X-axis), 55mm (Y-axis).

Power Supply
Universal AC input, external SMPS adapter available.

Color
White body with contrasting black stage.

Head Lock
Head lock device for secure transport and safety.

Nosepiece
Quadruple ball-bearing revolving nosepiece, reversed orientation.

Application Areas
Clinical, research laboratories, education, diagnostics, pathology, microbiology.

Body Material
Rugged aluminum alloy cast for durability.

Transformer
Built-in, for wide voltage range 100-240V AC, 50/60Hz.

Stage Movement
Low-position coaxial control for smooth X-Y movement.

Anti-mold Coating
Optical components coated for tropical, humid environments.

Stage Size
145mm x 140mm.

Magnus MX21i TR LED Trinocular Microscope Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About Magnus MX21i TR LED Trinocular Microscope

Experience the paragon of microscopy with the Magnus MX21i TR LED Trinocular Microscope-a meritorious choice for professionals demanding elite performance. Crafted with a rugged aluminum alloy cast, its resplendent build ensures enduring durability. The reversed quadruple ball-bearing nosepiece and smooth mechanical stage provide seamless operation. Achieve ephemeral clarity with infinity-corrected achromatic objectives and robust LED illumination. Its advanced trinocular Seidentopf head, anti-fungal optics, and wide voltage range empower clinical, research, and educational settings. Add to Cart to elevate your laboratory to world-class standards.

Elite Versatility for Professional and Academic Settings

The Magnus MX21i TR LED Trinocular Microscope is meticulously engineered for routine diagnostics, in-depth research, and educational use. Equipped with infinity-corrected objectives, anti-mold coated optics, and ergonomic low-position controls, it delivers both performance and comfort. Its universal power adaptability, resplendent LED illumination, and robust mechanical stage make it a competitive asset, ensuring reliability and precision for clinicians, researchers, and students alike.

Sample Access, Accreditation, and Swift Handover

Sample units of the Magnus MX21i TR LED Trinocular Microscope are available for preliminary outlay, ideal for institutions and laboratories. The device boasts meritorious certifications reflecting its rigorous quality standards. With a flexible supply ability, clients can expect express shipping and prompt handover, minimizing downtime. Our dedicated support ensures an optimized procurement experience, delivering your elite instrument securely and on schedule.

FAQ's of Magnus MX21i TR LED Trinocular Microscope:

Q: How can the Magnus MX21i TR LED Trinocular Microscope benefit research and diagnostics?

A: The Magnus MX21i TR offers advanced optical clarity, robust mechanical performance, and ergonomic controls, making it ideal for accurate diagnostics and detailed research workflows. Infinity-corrected objectives and variable LED illumination allow for high-resolution observations in clinical, pathology, and microbiology labs.

Q: What distinguishes the Magnus MX21i TR from competitor microscopes?

A: Its resplendent durability, anti-mold optical components, and reversed quadruple nosepiece, combined with the elite trinocular head for imaging, set it apart. The microscope's universal voltage compatibility, rugged aluminum body, and option for digital camera adaptation underscore its superiority.

Q: When is a sample unit available for evaluation before purchase?

A: Sample units are available on request for evaluation, allowing institutions to assess the microscope's performance prior to significant outlay. Reach out to the supplier to arrange a demonstration or sample handover.

Q: Where is the Magnus MX21i TR most commonly used?

A: This meritorious microscope finds applications in clinical and research laboratories, diagnostics, pathology, microbiology, and educational institutions where high optical precision and reliability are essential.

Q: What is the process for procuring and receiving the microscope?

A: Simply contact your distributor or supplier, confirm your requirements, and complete your order. Express shipping is available, ensuring prompt handover and secure delivery of your instrument.

Q: How does the anti-mold coating enhance the device's usability?

A: The anti-mold coating on optical components ensures optical clarity and longevity, especially in tropical or humid environments, making the device highly reliable for consistent use.
