MagZoom TZM12 TR

Name: MagZoom TZM12 TR
Brand: M/S Uvsar India
Price: 657690.0 INR
Availability: InStock

Price 657690.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MagZoom TZM12 TR Specification

Features
High-definition imaging, Multi-interface output, Adjustable magnification, LED illumination, Real-time viewing

Focus System
Coarse & Fine focus

View Head
Trinocular, 360 rotatable

Spare Parts
Dust cover, Power adapter, Instruction manual

Theory
Digital Trinocular Zoom Microscope

Drawtube
Trinocular

Sensor
1/2.8 Sony CMOS

Resolution
1920 x 1080

Interface
USB, HDMI, TF card

Frame Rate
60fps

Focal Distance
95mm

Magnification
7x-45x

Dimensions
330 x 320 x 430mm

Focus Range
10cm to Infinity

Eyepieces
WF10x/20mm

Eyepiece Tube
30 inclined, 360 rotatable

Illumination
LED Ring Light (Adjustable)

Coarse Adjustment Range
55mm

Fine Adjustment Range
0.002mm

Working Stage
Double layer mechanical stage, size 190x155mm

Still Image Capture Resolution
1920 x 1080

Video Capture Resolution
1920 x 1080

Image Format
JPEG

Interpupillary Distance
54-76mm

Objective Achromatic
0.7-4.5x

Light Source
LED Ring Light

Photo/Video Storage
Supports TF card up to 32GB

Weight
Approx. 6.5 kg

Software
Image analysis software included

Camera Output Mode
Simultaneous HDMI/USB/TF Card output

Compatible Operating System
Windows 7/8/10

Stage Movement
76mm (X-Y direction)

Power Supply
110-240V AC, 50/60Hz

Operating Temperature
0C to 40C

Stand Type
Heavy base with anti-slip pad

MagZoom TZM12 TR Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About MagZoom TZM12 TR

MagZoom TZM12

Trinocular Stereo Zoom Microscope Model TZM12 consisting of Zoom Ratio 1:12.5, Zoom range

0.63X8X, builtin aperture diaphragm, tilting Trinocular head (545), beam splitter ratio 100:0,

0:100, IPD 50-76 mm , Plan Apochromat objective 1x (WD 78 mm), paired wide field eyepiece 10X

(F.No. 22), diopter adjustable , Co-axial coarse & fine focusing mechanism, ultra-thin multi LED base

of 5W & LED ring lamp for reflected light, C-Mount adapter of 0.5x, transparent glass plate & black

and white plate, dust cover complete set.

Advanced Imaging and Connectivity

The MagZoom TZM12 TR provides simultaneous HDMI, USB, and TF card outputs, allowing users to display, capture, and record images or videos in real time. Its 1/2.8 Sony CMOS sensor ensures high-definition visuals, perfect for analysis or live sharing. Compatible with Windows 7, 8, and 10, it includes comprehensive image analysis software for streamlined workflow.

Versatile Magnification and Optics

With a seamless zoom range of 7x to 45x and WF10x/20mm eyepieces, users can inspect specimens with remarkable detail. The trinocular, 360 rotatable head and adjustable interpupillary distance accommodate multiple viewing angles and users. Enhanced with achromatic objectives, it guarantees clear and accurate visual results.

User-Friendly Design and Accessories

Engineered for user comfort, it features a heavy base with an anti-slip pad, spacious double-layer mechanical stage, and both coarse and fine focus controls. Accessories such as a dust cover, power adapter, and instruction manual further facilitate easy setup and maintenance, making it suitable for busy labs and classrooms alike.

FAQ's of MagZoom TZM12 TR:

Q: How can I record and store both photos and videos on the MagZoom TZM12 TR?

A: The MagZoom TZM12 TR supports photo and video storage via a TF card (up to 32GB). Simply insert a compatible TF card into the slot, and use the included image analysis software to capture still images or video clips directly during observation.

Q: What are the connectivity options for viewing and transferring images from the microscope?

A: This microscope offers simultaneous HDMI, USB, and TF card outputs. You can connect it to monitors, computers, or projectors in real time, or save files to the TF card. This makes sharing and transferring data highly convenient in multiple environments.

Q: When should I use the coarse and fine focus adjustments?

A: Use the coarse focus for rapid positioning of your sample and the fine adjustment (with 0.002mm precision) when you require exceptional clarity for detailed imaging or measurements. Both systems ensure accurate focus for different magnification levels.

Q: Where should the MagZoom TZM12 TR be installed for optimal performance?

A: Place the microscope on a flat, stable surface where the anti-slip base can firmly grip. Ensure the operating temperature stays between 0C and 40C. Position it in an environment free from excessive dust and vibrations for best image stability and equipment longevity.

Q: What process should be followed to operate the MagZoom TZM12 TR using its included software?

A: Connect the microscope to a Windows 7, 8, or 10 PC via USB. Install the provided image analysis software, and follow the instructions in the manual for capturing, analyzing, and exporting images and videos. The software simplifies real-time viewing and post-capture analysis.

Q: How does the LED ring light benefit the observation process?

A: The adjustable LED ring light provides consistent, shadow-free illumination, enhancing contrast and detail in specimens. Its brightness can be modified based on sample requirements, ensuring clear visualization across varying magnifications and sample types.

Q: What are the main applications and benefits of using the MagZoom TZM12 TR?

A: This microscope is ideal for research, industrial inspection, and educational demonstration. Its high-definition imaging, versatile output options, and user-friendly design offer efficient, reliable observation for quality assurance, documentation, and collaborative work.
