Trinocular Microscope Model ICON LED TR PLUS

Name: Trinocular Microscope Model ICON LED TR PLUS
Brand: M/S Uvsar India
Price: 43450.0 INR
Availability: InStock

Price 43450.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Trinocular Microscope Model ICON LED TR PLUS Specification

View Head
Trinocular head

Features
LED illumination, ergonomic controls, robust body, camera adaptability

Spare Parts
Eyepieces, objectives, fuse, bulb, stage clips

Focus System
Coaxial coarse & fine adjustment

Theory
Microscope for biological observations with LED illumination and trinocular head for camera attachment.

Drawtube
Trinocular, 360 rotatable

Sensor
Compatible with integrated or external digital cameras (camera not included)

Resolution
Depends on the attached camera (common options: 640x480/1280x1024/1920x1080 and above)

Interface
Compatible with standard c-mount camera ports

Frame Rate
Depends on camera, up to 30fps with compatible models

Focal Distance
Adjustable with coarse and fine focus

Magnification
40X to 1000X (using provided objectives and eyepieces)

Dimensions
Approx. 320x270x430 mm (LxWxH)

Focus Range
Coarse: 30mm; Fine: 0.002mm division

Eyepieces
Widefield 10x and 20x, paired (two pieces each)

Eyepiece Tube
Trinocular standard, suitable for photo and video

Illumination
Built-in long-life white LED lamp with adjustable intensity

Coarse Adjustment Range
30mm

Fine Adjustment Range
0.002mm division

Working Stage
Mechanical double-layer stage, size approx. 140x140mm, travel range 75x50mm

Still Image Capture Resolution
Up to 5MP (with appropriate camera)

Video Capture Resolution
Up to 1920x1080 (with appropriate camera)

Image Format
JPEG/BMP/AVI (depends on attached camera specification)

Interpupillary Distance
Adjustable, 55mm to 75mm

Objective Achromatic
DIN Standard 4X, 10X, 40X (spring), 100X (spring, oil immersion)

Condenser
Abbe N.A. 1.25 with iris diaphragm and filter holder

Light Source
High-power LED, adjustable brightness

Nosepiece
Quadruple backward revolving nosepiece with positive click stop

Body Material
Heavy-duty cast alloy with anti-rust coating

Color
White and black finish

Packaging
Thermocol box with export quality carton for safe transit

Stage Scale
Graduated scale for precise measurement

Operating Temperature
10C to 40C (recommended)

Power Supply
AC 220V/110V, 50/60Hz; protection fuse provided

Packed Accessories
Power cord, dust cover, oil bottle, user manual

Field Diaphragm
Built-in for even illumination

Dust Cover
Included

Trinocular Microscope Model ICON LED TR PLUS Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About Trinocular Microscope Model ICON LED TR PLUS

Magnus Laboratory & Education Trinocular Microscope Model ICON LED TR PLUS standard

microscope set complete with LED illumination, quadruple ball bearing nosepiece with inward tilt &

positive click stop, co-axial coarse and fine focusing control, Achromat objectives 4x, 10x, 40x

(spring) & 100x (spring, oil immersion), 30 degrees inclined & 360 degrees rotatable trinocular tube

with interpupillary distance distance adjustment (IPD) range of 4875mm, fungus resistant optics,

widefield paired eyepiece of 10x (F.N.18) with diopter setting of +/- 5mm on left side of tube, right

hand control co-axial double layer mechanical stage with stage size of 130 X 130 mm with single

slide holder, focusable Abbe condenser 0.9/1.25 N.A complete set.

Exceptional Imaging and Versatility

Equipped with a trinocular head and compatible with a wide range of camera systems, the ICON LED TR PLUS enables effortless photomicrography and live video capture for documentation or presentations. Its accurate focusing system and broad magnification range make it ideal for diverse biological studies and detailed analysis.

Precision Engineering and Robust Design

Engineered with a heavy-duty cast alloy frame finished in a protective anti-rust coating, the ICON LED TR PLUS ensures durability for frequent, intensive use. The ergonomic design, including a mechanical double-layer stage and precise graduated scale, facilitates accurate sample navigation and measurement for rigorous laboratory work.

Enhanced Illumination for Clarity

Featuring built-in field and iris diaphragms, along with an energy-efficient high-power LED lamp, the microscope guarantees uniform, adjustable illumination to suit various specimen types. The adjustable brightness supports optimal visibility even during extended observation sessions.

FAQ's of Trinocular Microscope Model ICON LED TR PLUS:

Q: How do I attach a digital camera to the Trinocular Microscope Model ICON LED TR PLUS?

A: Attach a compatible digital camera (not included) to the standard c-mount port on the trinocular head. You may use either integrated or external cameras, ensuring they fit the interface for optimal photo or video capture.

Q: What is the recommended operating environment for this microscope?

A: The recommended operating temperature for the ICON LED TR PLUS is between 10C and 40C, ensuring stable functioning and longevity of the components.

Q: How is precise focusing achieved on this model?

A: The microscope offers coaxial coarse (30mm range) and fine (0.002mm division) adjustment knobs, enabling smooth and accurate focusing for high-resolution observations at all magnifications.

Q: Where can this microscope be used effectively?

A: This model suits educational laboratories, research institutions, clinical setups, and advanced teaching environments-any setting requiring high-quality biological imaging and measurement.

Q: What accessories come packed with the microscope?

A: Each ICON LED TR PLUS is supplied with a power cord, dust cover, oil bottle, and a user manual, all safely packaged in export-quality thermocol and cartons to protect during transit.

Q: What are the benefits of the built-in LED illumination system?

A: The integrated high-power white LED lamp delivers long-lasting, energy-efficient illumination with adjustable brightness, ensuring clear and evenly lit images-a crucial aspect in microscopic analysis.

Q: How does the graduated stage scale improve the usage process?

A: The graduated mechanical stage, with a 75x50mm travel range and precise scale, streamlines precise sample movement and measurement, facilitating accurate documentation and repeatability in experiments.
