MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE

Send Inquiry

Request To Call Back

MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE

Name: MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE
Brand: M/S Uvsar India
Price: 64325.0 INR
Availability: InStock

Price 64325.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE Specification

Spare Parts
Fuses, LED module, eyepieces, objectives, mechanical stage accessories

View Head
Binocular, 360 rotatable

Features
Freedom from corded power supply, anti-fungus coating, ergonomic design, maintenance-free

Focus System
Coaxial coarse & fine focus system, adjustable tension

Theory
Binocular Compound Microscope designed for advanced laboratory and clinical applications

Drawtube
Binocular, 45 inclined, 360 rotatable

Magnification
40X to 1000X (using eyepieces and objectives)

Dimensions
Approx. 370mm (H) x 200mm (W) x 260mm (L)

Focus Range
Coarse and Fine Adjustment with long range

Eyepieces
Paired 10X & 20X Wide Field Eyepieces (anti-fungus coated)

Eyepiece Tube
Binocular inclined 45

Illumination
Transmit LED Illumination with rechargeable battery

Coarse Adjustment Range
30mm

Fine Adjustment Range
0.002mm graduation

Working Stage
Double layer mechanical stage, size 135 x 120 mm, movement range 70 x 30 mm

Interpupillary Distance
55 to 75 mm adjustable

Objective Achromatic
4X, 10X, 40X, 100X (oil), DIN Standard, Achromatic anti-fungus

Condenser
Substage Abbe Condenser NA 1.25, iris diaphragm, focusable

Light Source
Rechargeable LED, 0.5W/LED, Battery backup up to 24 hours

Weight
Approx. 7 kg

Battery Type
Rechargeable lithium-ion

Nosepiece
Reverse quadruple nosepiece with positive click stop

Stage Graduation
0.1 mm

Stage Movement Mechanism
Low positioned coaxial drive controls

Color
White & black

Power Supply
100-240V, 50/60Hz AC adapter

Body Material
Sturdy aluminum alloy with anti-rust coating

Application
Laboratory, educational, and clinical use

MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE

Pick yours from our featured, top-tier selection-the MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE. This magnificent instrument is designed for stellar clarity and ravishing precision. Its 45 inclined, 360 rotatable binocular head, combined with anti-fungus optics and achromatic objectives, ensures vivid imagery from 40X to 1000X magnification. The sturdy aluminum alloy body resists rust, while the rechargeable LED powers up to 24 hours-granting true freedom from corded supply. Ending soon, this advanced microscope is an indispensable choice for laboratories, educational domains, and clinical settings.

Optimal Laboratory and Educational Utility

The MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE is crafted for commercial laboratories, educational institutions, and clinical research centers. Its low-position coaxial drive controls and wide field eyepieces guarantee effortless and precise observations. To use, simply plug in the adapter or rely on the built-in battery, adjust the ergonomic binocular head, and select the desired magnification for crystal-clear results. Robust for continuous usage, it simplifies complex examinations across scientific disciplines.

Efficient Domestic Distribution and Sample Policy

With the ability to supply, ship, and deliver across the main domestic market, the MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE is readily available for laboratories and institutions nationally. Sample policies are in place to facilitate evaluation prior to commitment. Swift supply ability ensures your orders are delivered promptly and efficiently, making scientific advancement accessible and convenient. Contact your local distributor or supplier for seamless delivery and after-sales support.

FAQ's of MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE:

Q: How does the MAGNUS MLXI PLUS FREEDOM BINOCULAR MICROSCOPE provide freedom from corded power?

A: It utilizes a rechargeable lithium-ion battery that powers the LED illumination for up to 24 hours, allowing you to operate the microscope anywhere without being tethered to a power outlet.

Q: What are the commercial uses of this microscope?

A: It is ideal for laboratory research, educational demonstrations, clinical diagnostics, and any setting requiring accurate, high-resolution microscopic observation.

Q: When should I use the fine adjustment knob?

A: The fine adjustment knob, with a precision of 0.002mm, should be used when you need to bring your sample into sharp focus at higher magnifications or delicate specimens.

Q: Where can spare parts or accessories for this microscope be obtained?

A: Spare parts such as fuses, LED modules, eyepieces, and stage accessories can be sourced directly from authorized distributors, suppliers, or traders listed by the manufacturer.

Q: What is the benefit of the anti-fungus coating on the eyepieces and objectives?

A: The anti-fungus coating protects the optical elements from fungal contamination, ensuring long-lasting clarity and low maintenance, especially in humid environments.

Q: How is the mechanical stage operated for precision?

A: The double-layer mechanical stage is moved using low-positioned coaxial drive controls, allowing for smooth, accurate sample positioning across a 70 x 30 mm range.
