MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM
MAGNUS CH20i BINOCULAR FREEDOM

MAGNUS CH20i BINOCULAR FREEDOM

Price 58580.0 INR/ Piece

MOQ : 1 Piece

MAGNUS CH20i BINOCULAR FREEDOM Specification

  • Spare Parts
  • Supplied with dust cover, immersion oil, power adapter
  • Focus System
  • Coaxial coarse & fine focusing system
  • View Head
  • Siedentopf Binocular
  • Features
  • Integrated digital imaging, on-screen measurement, microSD support, live HDMI display, ergonomic build
  • Theory
  • Binocular Freedom Digital Imaging System with integrated camera and display for real-time visualization.
  • Drawtube
  • Binocular
  • Sensor
  • CMOS digital sensor
  • Resolution
  • Full HD 1920 x 1080 pixels
  • Interface
  • USB 2.0, MicroSD card, HDMI output
  • Frame Rate
  • Up to 30 fps
  • Focal Distance
  • Approx. 160 mm
  • Magnification
  • Up to 2000X (with digital zoom and objective combination)
  • Dimensions
  • Approx. 365 mm x 210 mm x 400 mm
  • Focus Range
  • Coarse & Fine focus
  • Eyepieces
  • Widefield 10X/20 mm
  • Eyepiece Tube
  • Inclined at 45
  • Illumination
  • LED with intensity adjustment
  • Coarse Adjustment Range
  • 15 mm per rotation
  • Fine Adjustment Range
  • 0.002 mm per division
  • Working Stage
  • Double layer mechanical stage, 135 mm x 125 mm, movement 75 mm x 40 mm
  • Still Image Capture Resolution
  • 1920 x 1080 pixels
  • Video Capture Resolution
  • 1920 x 1080 pixels
  • Image Format
  • JPG (still), AVI (video)
  • Interpupillary Distance
  • 55 - 75 mm adjustable
  • Objective Achromatic
  • 4x, 10x, 40x, 100x oil
  • Condenser
  • Abbe condenser NA1.25, with iris diaphragm
  • Light Source
  • LED 3W with adjustable brightness
  • Display
  • Integrated 7-inch LCD screen
  • Operating Temperature
  • +10C ~ +40C
  • Power Supply
  • AC 100-240V, 50/60Hz, DC 5V
  • Battery Backup
  • Built-in rechargeable lithium battery
  • Camera Output
  • Direct monitor, HDMI and digital capture
  • Storage Temperature
  • -20C ~ +60C
  • Body Material
  • Metal frame


MAGNUS CH20i BINOCULAR FREEDOM Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Delivery Time
  • 5 Week


About MAGNUS CH20i BINOCULAR FREEDOM

MAGNUS CH20i BINOCULAR FREEDOM
Magnus Binocular microscope Model CH20i  Freedom same as above "MODEL CH20i LED" WITH battery back-up
