Send InquiryMAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXI PLUS PRO FREEDOM WITH NO AUTO LED OFF
Price 68415.0 INR/ Piece
MOQ : 1 Piece
MAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXI PLUS PRO FREEDOM WITH NO AUTO LED OFF Specification
- View Head
- Binocular Siedentopf head, 30 inclined, rotatable 360.
- Features
- Freedom from automatic LED off, robust metal frame, anti-fungus optics, ergonomic design for prolonged use.
- Spare Parts
- Supplied with dust cover, spare fuse, and immersion oil.
- Focus System
- Coaxial coarse and fine focusing mechanism with tension adjustment.
- Theory
- Advanced Laboratory Binocular Microscope designed for precise scientific analysis and routine laboratory work.
- Drawtube
- Binocular; 360 rotatable, inclined at 30 for ergonomic viewing.
- Sensor
- Not applicable (standard optical system).
- Resolution
- High optical resolution provided by precision-ground optics.
- Interface
- Manual operation; option for camera attachment via phototube (not included in base model).
- Frame Rate
- N/A (no built-in camera).
- Focal Distance
- Optimal working distance as determined by objective; typically 0.17mm cover glass thickness compatibility.
- Magnification
- 40x to 1000x (using supplied objectives and eyepieces).
- Dimensions
- Approx. 370mm (h) x 230mm (w) x 430mm (d) consolidated design.
- Focus Range
- Wide focus range supported by coarse and fine adjustment knobs.
- Eyepieces
- Paired widefield 10x (WF10x) eyepieces, anti-fungus, high-eyepoint type.
- Eyepiece Tube
- Binocular, adjustable interpupillary distance 55 - 75 mm.
- Illumination
- High-intensity LED illumination (white light) with variable intensity; NO automatic LED shut-off.
- Coarse Adjustment Range
- Approx. 20 mm movement range.
- Fine Adjustment Range
- Fine focus graduation 2 m per division.
- Working Stage
- Precision mechanical stage with low-position coaxial X-Y controls, size approximately 135 x 140 mm.
- Still Image Capture Resolution
- N/A (depends on external camera if attached).
- Video Capture Resolution
- N/A (depends on external camera if attached).
- Image Format
- N/A (microscope is optical; optional camera attachment allows digital capture).
- Interpupillary Distance
- 55 - 75 mm adjustable.
- Objective Achromatic
- DIN standard achromatic objectives: 4x, 10x, 40x (spring), 100x oil (spring).
- Condenser
- Abbe condenser, N.A. 1.25, with iris diaphragm and filter holder.
- Light Source
- Built-in long-lasting white LED with intensity control, NO auto-off feature.
- Body Material
- Die-cast metallic body for durability and stability.
- Power Supply
- 100-240V AC, internal power supply.
- Intended Use
- Clinical, research, and educational laboratory applications.
- Anti-Mold Construction
- Optical components anti-fungal treated, ideal for Indian/Asian climates.
- Weight
- Approx. 8.5 kg (net weight).
- Illumination Voltage
- Variable LED, consistent output for long operation.
- Nosepiece
- Quadruple (reversed) ball-bearing nosepiece for smooth objective switching.
- Stage Movement Range
- X-axis and Y-axis movement approximately 75mm x 40mm.
- Safety Certifications
- CE compliance for safety and quality assurance.
- Stage Lock
- Stage upstopper prevent slide damage during focusing.
MAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXI PLUS PRO FREEDOM WITH NO AUTO LED OFF Trade Information
- Minimum Order Quantity
- 1 Piece
- Delivery Time
- 5 Week
About MAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXI PLUS PRO FREEDOM WITH NO AUTO LED OFF
MAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXi Plus PROFreedom with 9V adapter complete with LED illumination with battery back (with no auto LED offfeature), universal SMPS power supply for main supply 100V240V, quintuple ball bearing inwardnosepiece, co-axial coarse and fine focusing control, Infinity corrected Plan AchromaticObjectives 4x, 10x, 20x, 40x (spring), 100x (spring oil ), 360 degree rotatable inclined Siedentopfbinocular observation tube with eyepoint height adjustment , fungus resistant coated optics fortropical conditions, widefield paired eyepiece WH10x (F.N.22) with one eyepiece having dioptersetting, right hand control co-axial low drive rackless mechanical stage with single slide holder,rack & pinion drive focusable Abbe condenser 0.9/ 1.25 N.A with iris diaphragm & cord holder.Robust Optical and Mechanical Precision
Experience superior clarity and smooth operation with the MLXI Plus Pro Freedom's DIN achromatic objectives and quadruple ball-bearing nosepiece. The coaxial coarse and fine focus controls, along with the precision mechanical stage, facilitate accurate specimen navigation and detailed analysis, essential for both education and advanced laboratory work.
Protection and Ergonomic Comfort
Anti-mold treated optical components safeguard the microscope's effectiveness in humid climates. Its ergonomic layout, including inclined binocular viewing and adjustable interpupillary distance, allows for extended, comfortable use, reducing strain during long sessions. The die-cast metal body provides exceptional stability and durability.
Consistent, Customizable Illumination
A variable, high-intensity white LED ensures reliable lighting for specimen observation, and the absence of auto shut-off enables continuous workflow without interruption. Easily control illumination intensity based on your sample and preference, making it suitable for various laboratory tasks.
FAQ's of MAGNUS ADVANCE LABORATORY BINOCULAR MICROSCOPE MODEL MLXI PLUS PRO FREEDOM WITH NO AUTO LED OFF:
Q: How does the MLXI Plus Pro Freedom ensure accuracy when navigating specimens?
A: The microscope features a precision mechanical stage with a substantial X-Y movement range (75mm x 40mm), low-position coaxial controls, and a stage lock (upstopper) to prevent damage, providing accurate and effortless specimen positioning during observation.Q: What are the benefits of the anti-mold construction for this microscope in Indian or Asian climates?
A: Anti-fungal treatment of all optical components prevents mold growth even in high-humidity regions, thereby preserving optical clarity and guaranteeing long-term performance in challenging climates.Q: When is this microscope suitable to use, and for what applications?
A: Designed for clinical, research, and educational settings, the MLXI Plus Pro Freedom is ideal for routine laboratory analysis, sample examination, and advanced scientific studies requiring reliable, high-resolution optics.Q: Where can users attach a camera to this microscope for digital imaging?
A: An optional camera can be mounted via the phototube (not included in the base model), enabling still image and video capture depending on the external camera specifications.Q: How does the constant LED illumination benefit laboratory workflows?
A: With variable intensity control and no automatic LED shut-off feature, users can maintain their focus on prolonged tasks without the distraction or workflow interruptions that can result from automatic lighting shut-off.Q: What safety and quality assurances are provided with this microscope?
A: The microscope is CE certified, confirming its compliance with essential safety and quality standards required for laboratory equipment.Q: What accessories and spare parts are included with the microscope package?
A: Each microscope is supplied with paired WF10x eyepieces, dust cover, spare fuse, and immersion oil, ensuring users have the essentials for immediate use and maintenance.
