Binocular Microscope Model ICON LED PLUS

Name: Binocular Microscope Model ICON LED PLUS
Brand: M/S Uvsar India
Price: 39500.0 INR
Availability: InStock

Price 39500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Binocular Microscope Model ICON LED PLUS Specification

Focus System
Coaxial Coarse and Fine Focusing

Features
Anti-fungal treated optics, Robust Metal Body, Smooth Mechanical Movements

View Head
Binocular, 360 Rotatable, 45 Inclined

Spare Parts
Dust Cover, Immersion Oil, Fuse, Instruction Manual

Theory
Compound Microscope with LED Illumination

Drawtube
Binocular, 360 Rotatable

Focal Distance
45mm Standard Distance

Magnification
40x to 1000x

Dimensions
Approx. 370 mm (H) x 270 mm (L) x 180 mm (W)

Focus Range
Coarse 15mm, Fine 0.002mm

Eyepieces
Paired 10x Wide Field

Eyepiece Tube
Inclined at 45, Binocular

Illumination
High Brightness White LED, Adjustable Intensity

Coarse Adjustment Range
15 mm

Fine Adjustment Range
0.002 mm

Working Stage
Rectangular Mechanical Stage 125mm x 115mm with Low-position Coaxial Controls

Interpupillary Distance
55-75 mm Adjustable

Objective Achromatic
4x, 10x, 40x (SL), 100x (SL) Oil Immersion

Condenser
Abbe Condenser NA 1.25 with Iris Diaphragm and Filter Holder

Light Source
LED, 220V/50Hz, 3W with Intensity Regulator

Power Supply
Universal AC 110V-240V Adapter Included

Color
White and Black

Stage Movement
75mm X 45mm

Safety
Over Current Protection for LED

Usage
Biological Observation, Educational & Laboratory use

Nosepiece
Quadruple Ball Bearing Reversed Nosepiece

Body Material
Rigid die-cast metal

Operating Temperature Range
10C - 40C

Optical System
Achromatic, Parfocal, Anti-Reflection Coated

Weight
Approx. 6 kg

Binocular Microscope Model ICON LED PLUS Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About Binocular Microscope Model ICON LED PLUS

Magnus Laboratory & Education Binocular Microscope Model ICON LED PLUS standard

microscope set complete with LED illumination, quadruple ball bearing nosepiece with inward tilt &

positive click stop, co-axial coarse and fine focusing control, Achromat objectives 4x, 10x, 40x

(spring) and 100x (spring, oil immersion), 30 degrees inclined & 360 degrees rotatable binocular

tube with interpupillary distance distance adjustment (IPD) range of 4875mm, fungus resistant

optics, widefield paired eyepiece of 10x (F.N.18) with diopter setting of +/- 5mm on left side of tube,

right hand control co-axial double layer mechanical stage with stage size of 130 X 130 mm with

single slide holder, focusable Abbe condenser 0.9/1.25 N.A complete set.

Precision Observation for Education and Research

ICON LED PLUS is meticulously engineered for both educators and laboratory professionals. With a robust body, advanced Stage Movement (75mm X 45mm), and precise focusing mechanics, it delivers reliability and high-resolution detail. This compound microscope's intuitive layout, smooth mechanical stage, and wide field of view empower users to conduct diverse biological investigations with confidence and ease.

User-Friendly and Ergonomic Design

The microscope's rotatable, inclined binocular head ensures comfortable prolonged usage, while the adjustable interpupillary distance suits various users. Ergonomic coaxial focusing and low-position stage controls make fine-tuning smooth and precise. Supplied with essential accessories, such as a dust cover and immersion oil, the ICON LED PLUS is ready for immediate, hassle-free use.

Advanced Optical Performance

Featuring anti-fungal treated achromatic optics and a high-brightness LED light source with intensity regulation, this microscope delivers crisp, vivid images across magnification settings from 40x to 1000x. The Abbe condenser with iris diaphragm and filter holder further refines illumination, allowing for detailed observation of specimens under varied conditions.

FAQ's of Binocular Microscope Model ICON LED PLUS:

Q: How do I adjust the magnification on the ICON LED PLUS microscope?

A: To change magnification, simply rotate the quadruple ball bearing nosepiece to select your desired objective lens (4x, 10x, 40x (SL), or 100x (SL) oil immersion). Each pairs with the 10x wide-field eyepieces for total magnifications from 40x to 1000x.

Q: What safety features are present in the ICON LED PLUS microscope?

A: The ICON LED PLUS is equipped with over-current protection for the LED illumination system, safeguarding both the microscope and user from electrical surges.

Q: When should immersion oil be used with this microscope?

A: Use the provided immersion oil only when viewing specimens with the 100x (SL) oil immersion objective lens. This enhances image clarity and resolution at high magnification.

Q: Where is the microscope suitable for use?

A: The ICON LED PLUS is ideal for both educational environments and laboratory settings, performing optimally within an operating temperature range of 10C - 40C.

Q: What benefits does the anti-fungal treated optics provide?

A: Anti-fungal treated optics prevent mold growth on optical surfaces, thereby maintaining image clarity and extending the lifespan of the microscope in humid or challenging environments.

Q: How do I maintain smooth mechanical movements in the stage and focus system?

A: Regularly clean the stage, lightly lubricate moving parts if needed, and keep the unit covered with the supplied dust cover when not in use to ensure long-lasting, smooth operation.

Q: What is the process for replacing the fuse or LED light source?

A: Both the fuse and LED light source are designed for straightforward replacement. Refer to the included instruction manual for step-by-step guidance on safely accessing and replacing these components.
