MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF

Send Inquiry

Request To Call Back

MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF

Name: MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF
Brand: M/S Uvsar India
Price: 72731.0 INR
Availability: InStock

Price 72731.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF Specification

View Head
Trinocular, 360 rotatable

Features
NO AUTO LED OFF, anti-fungal coating, robust construction, high precision focusing

Spare Parts
Supplied with dust cover, immersion oil, fuse, operation manual

Focus System
Coaxial coarse and fine focusing with torque adjustment

Theory
Advanced Laboratory Trinocular Microscope for professional and clinical use

Drawtube
Trinocular, 360 rotatable

Sensor
Not applicable (microscope without integrated digital sensor)

Resolution
Dependent on eyepiece and objective combination (up to 1000x optical magnification)

Interface
Trinocular tube compatible with camera adapters

Frame Rate
N/A (non-digital microscope)

Focal Distance
Standard for laboratory biological microscopes (approx. 160mm mechanical tube length)

Magnification
40x - 1000x (using supplied eyepieces and objectives)

Dimensions
Approx. 425mm x 210mm x 390mm (H x W x D)

Focus Range
Coarse and fine adjustment, 30mm coarse; fine graduation: 0.002mm

Eyepieces
Paired WF10x/20mm anti-fungal coated

Eyepiece Tube
Trinocular, inclined at 30

Illumination
Built-in high-intensity LED illumination, adjustable brightness, NO AUTO LED OFF

Coarse Adjustment Range
30mm

Fine Adjustment Range
2m (0.002mm)

Working Stage
Built-in double layer mechanical stage, size: 140 x 140mm, travel range: 80 x 55mm

Still Image Capture Resolution
Depends on external camera (optional, via trinocular port)

Video Capture Resolution
Depends on external camera (optional, via trinocular port)

Image Format
Dependent on camera used (optional through trinocular port)

Interpupillary Distance
48mm - 75mm adjustable

Objective Achromatic
4x, 10x, 40x (spring loaded), 100x oil (spring loaded), DIN standard, anti-fungal coated

Condenser
Abbe condenser N.A. 1.25 with iris diaphragm and filter holder

Light Source
High power 3W LED (cool white), variable intensity, NO AUTO OFF feature

Anti-Fungal Protection
All optics (eyepiece and objectives) have anti-fungal coating for tropical environments

Diopter Adjustment
On left eyepiece

Body Material
Sturdy metal stand with ergonomic design

Nosepiece
Quadruple revolving nosepiece with positive click stops

Power Supply
Universal input AC 100-240V, 50/60Hz, built-in transformer

Immersion Oil
Supplied for use with 100x objective

Color
White & blue body finish

Head Inclination
30 for comfortable viewing

Dust Cover
Included

Stage Dimensions
140 x 140mm double layer mechanical stage

Stage Movement
80 x 55mm X-Y movement

MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Week

About MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF

MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO

Freedom with 9V adapter complete with LED illumination with battery back (with no auto LED off

feature), universal SMPS power supply for main supply 100V240V, quintuple ball bearing inward

nosepiece, co-axial coarse and fine focusing control, Infinity corrected Plan Achromatic

Objectives 4x, 10x, 20x, 40x (spring), 100x (spring oil ), 360 degree rotatable inclined Siedentopf

trinocular observation tube with eyepoint height adjustment , fungus resistant coated optics for

tropical conditions, widefield paired eyepiece WH10x (F.N.22) with one eyepiece having diopter

setting, right hand control co-axial low drive rackless mechanical stage with single slide holder,

rack & pinion drive focusable Abbe condenser 0.9/ 1.25 N.A with iris diaphragm & cord holder.

Ergonomic and Durable Design

This microscope is constructed with a sturdy metal stand and finished in white and blue, ensuring both durability and a modern appearance. Its ergonomic features, such as a 30 inclined trinocular head and adjustable interpupillary distance, provide comfortable long-term use in laboratory settings.

High-Quality Optics

Equipped with anti-fungal coated objectives and eyepieces (WF10x/20mm), the MLXi Tr Plus PRO Freedom delivers sharp, clear images under demanding tropical conditions. Achromatic 4x, 10x, 40x (spring-loaded), and 100x oil objectives provide an impressive 40x to 1000x magnification range.

Versatile Laboratory Performance

The advanced double-layer mechanical stage (140 x 140mm) with smooth X-Y movement (80 x 55mm) allows precise sample positioning. The Abbe condenser (N.A. 1.25, iris diaphragm) and variable LED illumination support a wide array of laboratory and clinical microscopy applications.

FAQ's of MAGNUS ADVANCE LABORATORY TRINOCULAR MICROSCOPE MODEL MLXi Tr Plus PRO Freedom WITH NO AUTO LED OFF:

Q: How do I adjust the focus on the MAGNUS MLXi Tr Plus PRO Freedom microscope?

A: This microscope features coaxial coarse and fine focus knobs. The coarse adjustment range is 30mm for rapid focusing, while the fine graduation of 0.002mm allows for precise focusing of specimens under high magnification.

Q: What benefits does the anti-fungal coating provide?

A: All eyepieces and objectives are treated with an anti-fungal coating, protecting the optics from fungal growth in humid or tropical environments, thus ensuring long-term performance and image clarity.

Q: When should the supplied immersion oil be used?

A: Immersion oil is intended for use with the 100x oil immersion objective. It enhances resolution and clarity at the highest magnifications by minimizing light refraction between the sample and the objective lens.

Q: Where can I attach a camera to this microscope?

A: The MLXi Tr Plus PRO Freedom trinocular microscope has a dedicated trinocular tube compatible with standard camera adapters, allowing integration with various digital or video cameras for image and video capture.

Q: What kind of samples can this microscope be used for?

A: Designed for advanced laboratory and clinical environments, it is suitable for biological, pathological, and educational sample analysis, including tissue sections, cells, and microorganisms.

Q: How does the NO AUTO LED OFF feature benefit laboratory work?

A: With no auto LED off function, the illumination remains consistent during lengthy observations or demonstrations, eliminating interruptions caused by automatic shutdowns during continuous use.

Q: What accessories are included with the microscope?

A: The package comes with a dust cover, immersion oil for the 100x objective, an operation manual, and a fuse, ensuring immediate and proper use from setup to daily operation.
